Garmin ECHOMAP UHD 73cv With LakeVü G3 And GT24UHD-TM Transducer

All the fishing tools are built-in to these chartplotter/sonar combos with keyed-assist touchscreen 7” displays. Enjoy built-in CHIRP traditional and Ultra High-Definition ClearVü and SideVü scanning sonars.

The 7” model supports the full line of Panoptix™ sonars and sharing capabilities for sonar, waypoints and routes (with other ECHOMAP UHD 7” and 9” and ECHOMAP Ultra 10” and 12” models).
This chartplotter comes with a GT24 transducer for Ultra High-Definition ClearVü scanning sonar, which shows you a crystal-clear image below your boat. Plus, you get Garmin high wide CHIRP traditional sonar for remarkable target separation.
Features:

• Experience unparalleled coverage and detail with preloaded LakeVü g3 inland maps featuring integrated Navionics® data that covers more than 17,000 lakes with up to 1’ contours.
• Create personalized fishing maps on-screen with 1’ contours. Keep the data to yourself, or share it with the Quickdraw Community on Garmin Connect™.
• Network Capable: If you have multiple compatible ECHOMAP UHD or ECHOMAP Ultra devices on your boat, you can share information — such as sonar, user data and charts — among them (7” and 9” models only).
• NMEA 2000 and NMEA 0183 compatible: Connect to autopilots, digital switching, weather, FUSION-Link™ audio system, media, VHF, AIS and more from one screen.
• ActiveCaptain compatible
• Force Trolling motor compatible
• Engine connectivity: Connect this chartplotter to different kinds of engines — including select Mercury and Yamaha® models — to see RPMs, fuel flow, temperature, trim and other important information at a glance. You may need additional hardware, so be sure to check with your engine manufacturer.
• Dimensions: 9.8″ x 5.5″ x 2.0″
• Display type: Touchscreen
• Display size: 6.1″ x 3.4″; 7.0″ diagonal
• Display resolution: 400 x 800 pixels
• Weight: 1.7 lb
• Bail or flush mount
• Accepts 1 microSD card up to 32 Gb max
• Saves 5000 waypoints, 50 saved tracks and 100 routes
• Supports Garmin Smartmode, AIS, DSC, Fushion-Link compatible radios, GCV Black Box sonar, Sailing features

In the Box:

• ECHOMAP UHD 73cv with LakeVü g3 for U.S.
• GT24UHD-TM transducer with 20 ft. cable
• Power/data cable
• Tilt/swivel mount with quick release cradle
• Flush mount
• Protective cover
• Hardware
• Documentation
